Camera
Image Sensor:1/3″ Progressive Scan CMOS
Min. Illumination:0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter time:1/3 s to 1/100,000 s
Lens:4mm@ F2.0 (6mm optional), Angle of view: 73.1°(4mm), 46°(6mm)
Lens Mount:M12
Day& Night:IR cut filter with auto switch
Wide Dynamic Range:Digital WDR
Digital noise reduction:3D DNR

Compression Standard
Video Compression:H.264/MJPEG
H.264 code profile:32 Kbps – 12 Mbps
Dual Stream:Yes

Max. Image Resolution:1280×960
Frame Rate:50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576), 25 fps (640 x 480)
60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480)
Image Settings:Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:Yes, zone configurable
ROI:Support

Network
Network Storage:Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS)
Alarm Trigger:Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols:TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function:One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access
System Compatibility:ONVIF, PSIA, CGI, ISAPI

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
Reset Button:Yes
