Camera
Image Sensor:1/3″ Progressive Scan CMOS
Signal System:PAL/NTSC
Min. Illumination:0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.028Lux @ (F2.0, AGC ON) ,0 Lux with IR
Shutter time:1/3 s to 1/100,000 s
Lens:4mm@ F2.0, Angle of view: 73.1°(6mm optional)
Lens Mount:M12
Day& Night:IR cut filter with auto switch
Wide Dynamic Range:Digital WDR
Digital noise reduction:3D DNR

Compression Standard
Video Compression:H.264/MJPEG
Video bit rate:32Kbps~8Mbps
Dual Stream:Yes

Max. Image Resolution:1280×960
Frame Rate:50 Hz: 25 fps (1280 × 960), 25 fps (1280 x 720), 25 fps (704 x 576),
25 fps (640 x 480)60 Hz: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576),30 fps (640 x 480)
Image Settings:Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:Yes, zone configurable
ROI:support
3D DNR:support

Network
Network Storage:NAS (Support NFS,SMB/CIFS)
Alarm Trigger:Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
Protocols:TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,802.1X,QoS,IPv6,Bonjour
General Function:User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask
System Compatibility:ONVIF, PSIA, CGI, ISAPI

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface

General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 10%, PoE (802.3af)
Power Consumption:Max. 4.8 W
Weather Proof:IP67
IR Range:Up to 30m
Dimensions:70×154.2×60.5 mm (2.8” × 6.2” × 2.4”)
Weight:500g (1.1 lbs)
